Selecteer een rij in onderstaande tabel, en klik daarna op "voeg toe aan jouw aanvraag"
Type Omschrijving CAD
M 302 • For remote or separately from the pump placing of the valves M 311, M 322, M323, M 324 or M 325 (if necessary combined with pressure control valve M 303)• Connection: ¼” BSP female
M 301 B • For mounting couplers or hoses• To be mounted on the pump when using connecting plate M 302 instead ofcontrol valve• Provided with pressure relief valve• Connection: ¼” BSP female (2x), 3/8” NPT female (1x)• Mounting of pressure gauge A 500 possible using nipple 100.581.104• Mounting pressure gauge A 150 possible using nipple 100.581.128
M 303 • For mounting unto the Pump or unto the connecting plate M 302 (below the connecting block M 301 or below the Valves M 311, M 322, M 323, M 324 or M 325• Pressure adjustable between 0 and 720 Bars
• For 6, 12, 25 and 50 liter Vari pumps
• For 6, 12, 25 and 50 liter Vari pump protection frames.
• For 6 and 12 liter Vari pumps.
• For 25 and 50 liter Vari pumps.
• For 25 and 50 liter Vari pumps.
• For 6, 12, 25 and 50 liter Vari pumps
HSR 0.5 U • For AIR Vari pumps
A 181 U • For AIR Vari pump (separately)
• For AIR Vari pump (to be mounted)
